Minimum Impedance	6.5Ω
Nominal Impedance (Passive)	8Ω
HF Nominal Impedance	8Ω
HF Transducer	2-inch ND2
Speaker Type	Full-Range, Mid-High, Two-Way, Wedges
Woofer Size	15inch
Powered or Passive	Passive
Frequency Response (-3 dB)¹	58 - 18000Hz
LF Nominal Impedance	8Ω
Max. SPL/1m (calc)²	132dB
Coverage (Nominal -6 dB) H	90/60°
LF Transducer	15-inch DVX3150A
Coverage (Nominal -6 dB) V	50/60°
System Power Handling (Continuous/Program/Peak)	600//2400Watts
Power Rating	2400W
LF Power Handling	500Watts
HF Power Handling	40Watts
Crossover Frequency	1500Hz
Enclosure Material	High Impact Polystyrene Composite
Grille	Polyester Powder Coated, 18GA Galvanized Steel
Sensitivity 1 W/1 m	98dB
Available Color	Black or white
Height	27.24" (692mm)
Width	17.56" (446mm)
Recommended High-Pass Frequency	36Hz
Depth	16.18" (411mm)
Internal Crossover	Switchable biamp or passive crossover
Weight Net	48.94lbs (22.2kg)
Family	ZxZxA
Chassis Size	381 mm
Input Connections	Parallel Neutrik® NL4

Soundking DB089 W
