| Minimum Impedance |
5.3 Ω |
| Rated Power RMS |
500 W |
| Peak Power |
2000 W |
| Sound pressure level |
| SPL 1 W / 1 m |
100 dB |
| Max. SPL 1 m (calculated with peak power) |
133 dB |
| Frequency Range (-10 dB) |
57 Hz to 20 kHz |
| Nominal Coverage Angle (Horizontal x Vertical) |
90° x 50° |
| X-Over Frequency |
1550 Hz |
| LF Transducer |
SMX2151, 15‘‘ (381 mm) Driver |
| HF Transducer |
DH3, 1.25‘‘ (32mm) Diaphragm Compression Driver |
| Connectors |
2x Neutrik Speakon NL4 Full-Range 1+ / 1- Wired through 2+ / 2- |
| Dimensions (W x H x D) |
445 mm x 660 mm x 445 mm (17.5“ x 26.0“ x 17.5“) |
| Net Weight |
28.3 kg (62.4 lbs) |
| Shipping Weight |
31.8 kg (70.1 lbs) |
| Enclosure material |
MDF with D-PUR PLUS |
| Grille |
Steel, Black Finish with Acoustic Gauze |
| Suspension |
3x M8 threaded Points — 1x on Each Side & 1x on the Rear of Enclosure |
